Introduction to the NTS Series Gyratory Screen

The Navector Gyratory Screen is a highly efficient circular screening machine specially designed for the high-volume, high-precision screening requirements of granular materials in industrial production. It can meet customers' demands for efficient and precise screening processes of granular materials.

I.Working Principle
Simulating manual screening motion, it combines the circular motion of the screen with a parabolic throwing motion by adjusting eccentricity, radial angle, and tangential angle, creating a three-dimensional rolling motion in both horizontal and vertical directions. The material disperses evenly across the entire screen surface from the center to the periphery, propagating axially in a spiral motion, thereby completing the screening process for fine particles.

II.Equipment Advantages

Screening diameter up to 3000mm, offering a large screening area

High output per unit area, resulting in higher screening efficiency

Capable of achieving precise separation in 1 to 6 grades

Larger screening machines are equipped with a pneumatic screen body lifting device for easy screen mesh replacement, reducing operator workload



III.Application Fields

Chemical Industry: Urea, Polyethylene, Synthetic Resin, Graphite, Fertilizer, Wood Powder, Urea-Formaldehyde Resin Powder, Activated Carbon, Silica Gel, etc.

Food Industry: Flour, Starch, Food Additives, Sweeteners, Sucralose, Aspartame, Citric Acid, etc.

Pharmaceutical Industry: Chinese Herbal Powder, Western Medicine Raw Materials, Pharmaceutical Intermediates, Cellulose, etc.



IV.Parameters

Parameter	Value
Material Size	20 μm – 20 mm
Capacity	1 kg/h – 50,000 kg/h
Bulk Density	20 – 10,000 g/l
Screen Aperture	20 μm – 20 mm
Screen Type	Stainless Steel Mesh or Perforated Plate
Number of Decks	1 – 5
Speed Range	180 – 280 min⁻¹
Screen Motion	Three-Dimensional
Acceleration	1.3 – 1.8 g / 60 – 80 mm Horizontal & 5 – 40 mm Vertical
Material	Carbon Steel, Stainless Steel 304/316
Surface Treatment	Brushed, Painted, Mirror Polished
